There’s also a web portal to perform tasks such as firmware upgrades, diagnostics, rebooting the robot, and so on. RoboStudio graphical control management tool for Windows and Android allows you to create, manage, and edit maps for each of the robots in your fleet in a way that’s similar to smart vacuum cleaners since it’s using the same SLAM technology. Several software tools are provided for the robot. Dimensions – 545 mm (L) x 465 mm (W) x 272 mm (H) without elevator controller hardwareĪs I understand it the Rockchip RK3399 single board computer is placed on top of the robotic platform to facilitate connection to the customer chassis, which for instance, you make use of the HDMI and audio features for a hospitality robot or any robot with a human machine interface (HMI).16 Ah (standard) good for 9.5 hours without payload, 25 Ah (optional) good for 15 hours without payload.Power Supply – SBC: 12V DC input, charging station: 25.5V/6A.Mapping – 5 cm resolution, 500 x 500m maximum area.2x bumper sensors triggered with physical collision.2x boundary sensors with 3cm detection range.
360° Lidar Sensor up to 25m range (option for 30m range).Up to 1.2m/s (4.3 km/h) by default, but can be customized to up to 1.5m/s (5.4 km/h).Network connectivity – Gigabit Ethernet RJ45 port, dual-band WiFi, 4G cellular with SIM card slot.Audio – 3.5mm audio (mic+headphone) jack, dual-channel 5W/8Ω amplifier header.Hermes wheeled robot platform specifications: It can be controlled with a REST API, programmed with C++ SDK, or a program called RoboStudio available for Windows and Android. Powered by a Rockchip RK3399 mainboard, the Hermes robot platform supports autonomous path-finding, robot collaboration, cross-floor delivery, smart obstacle avoidance, safety features, and autonomous Recharging. SLAMTEC Hermes robot platform is a programmable wheeled robot that can take payloads of up to 60 kg across multiple floors thanks to an optional elevator controller, which makes it suitable for hotels, hospitals, airports, warehouses, transportation hubs, surveillance robot, and more.
